BF-3112
Return
BF-3112
BF-3112
BF-3112

Professional FM Transceiver

BF-3112

Rough design, rotary switcher, easy handle, and versatile function make BF-3112 one of the hot sale models.
Brochure
Inquiry
Features & Benefits
Specification
Accessories


VOX

Channel scan

Audio announce

PC programming

Low battery alarm

Time out timer (TOT)

Wide/narrow band switch

Busy channel lockout (BCL)

Voice Announcement

High capacity battery

16 Programmable Channels



General
Frequency range
136-174MHz 350-390MHz 400-470MHz
Channels
16
Channel spacing
25 KHz /12.5 KHz
Working temperature
-20℃～+60℃
Antenna impedance
50Ω
Operating voltage
DC3.7V(±20%)
Battery capacity
2500mAh(Li-ion)
Frequency stability
≤±2.5 ppm
Dimension
59×39×121mm
Weight
196g
Transmitter
Output power
≤5W
Modulation
　16KΦF3E(width)/8K50F3E(narrow)
Noise and harmonic
≤-36dBm
FM noise
≤-40dB
Rated audio distortion
≤5%
Adjacent power
≥65 dB(width)/55 dB(narrow)
Modulation limitation
≤5KHz(width)/2.5KHz(narrow)
Receiver
Sensitivity
≤0.165μV(Width)/ 0.2μV (narrow)
Adjacent selectivity
≥60dB(width)/ 50dB (narrow)
Intermodulation rejection ratio
≥60dB(width)/ 50dB (narrow)
Spurious suppression
≥60dB(width)/ 50dB (narrow)
SNR
≥45dB(width)/ 40dB (narrow)
Rated audio output power
0.5W
Rated audio distortion
≤5%
Standard Accessories
BF-RA301L
BF-RA301L
